HOLDWIN-5804H UV

Print Heads: Epson i3200-U1 * 4

Colors: CMYK + W + V

printing speed: 3 m²/h

Chat Now

PRODUCT DETAILS

Features

3D Printed Textured Hot Foil Stamping Process

Third Layer Second Layer First Layer

Embossed Texture Painting Golding Process on three-dimensional textured surfaces for gilding treatment to enhance decorative effects and texture. After gilding, the embossed texture painting’s gilded areas will have significant improvements in both tactile and visual effects, with text and images displaying strong metallic luster and vivid colors that are eye-catching. This process is widely applied in various fields such as decorative paintings, packaging, book covers, etc., able to increase product decoration and class.

Multi-layer printing technology for various texture solutions in one go

White ink texture, UV full color, matte oil, hot gold light oil multi-solution combination into one molding, can achieve 3D texture relief cultural and artistic product hot gold enhancement effects, all available through HOLDWIN-5804H UV one-time printing molding. It meets the application needs of more customers for texture relief solutions, demonstrates new printing expression techniques, and enhances product added value.

Texture+CMYK Texture+CMYK+ Matte Varnish Texture+CMYK+ Binder Varnish Texture+CMYK+ Binder Varnish +Matte Varnish

Using UV printing technology, the UV ink is sprayed onto the substrate by the printhead, then instantly cured with ultraviolet light. During the printing process, by controlling the specific white ink thickness, a raised, uneven relief effect can be formed. The colored ink is then overlaid on top of the white ink, resulting in a richly colorful and highly three-dimensional image.

• Support printing with varying precision and thickness • Applicable to multiple materials • Customization options • Long-lasting vibrant colors • Wide range of applications

Configuration parameters

– Configuration 6 Epson i3200 print heads, using 3.5 pl droplet textured relief printers;

– 1.8m UV white ink texture relief, matte oil, hot gold glossy oil, eight-color configuration conveyor printer;

– Reasonable nozzle layout and integrated printing of more solutions allow users to truly experience brand-quality products.

Applications

The 3D textured relief solution is widely applied in various fields, including but not limited to exhibition halls and galleries, advertising cultural background walls, decorative paintings, and art reproduction:

Exhibition Halls & Galleries: Inkjet printing technology with textured relief can be used for creating embossed wall prints on cloth and embossed print panels, making the displayed content stand out vividly and adding dynamic and attractive elements to the exhibition space;

Advertising Production: This technology can be applied in advertising production by using small text, lines, and textured reliefs to make the ad content more prominent and capture more attention;

Decorative Product Manufacturing: Inkjet printing technology with textured relief can be used to create various decorative items such as home decor paintings and crafts, by printing out raised or recessed textures that enhance the three-dimensional feel and artistic appeal of the products;

Art Reproduction: The technology can also be used for art reproduction, achieving precise replication of the original work through high-precision printing techniques while maintaining the texture and color of the original piece.

Technical Parameters

Model		HOLDWIN-5804H UV
Print Head		Epsonl3200-U1 * 4
Printing Technology		Gray-scale piezoelectric inkjet printing
Ink Drop		3.5 pl
Printing Width		1800 mm
Acceptable Media	Width	1820 mm
	Thickness	1 mm
	Weight	60 kg
Ink Curing Unit		Dual UV LED Lamps (Water-cooling UV lamp)
Ink	Type	UV Ink
	Capacity	Continual Ink Supply System(1.5L ink tank)
	Color	CMYK/CMYK+W/CMYK+W+CMYK/Scrub/Gild
Printing Resolution		300 / 600 / 900 / 1200 dpi
Interface		LAN
Power Supply		AC 220V士10%, 16A, 50 HZ 士 1, 5000W
RIP		Riprint UV
Machine size /weight		3400 * 1050 * 1592 mm / 450 kg
Package size /weight		3350 * 1130 * 1740 mm / 520 kg
Environment	Power on	Temperature:15℃ to 32℃/Humidity:35 to 80%(no condensation)
Environment	Power off	Temperature:5℃ to 40℃/Humidity:20 to 80%(no condensation)
Accessories		USB cable,media clamp,manual,drain bottle,ink cartridges,RIP software,etc.

Q&A

Q: What is the brand of this printing machine?
A: The brand of this printing machine is HOLDWIN.

Q: What is the model number of the HOLDWIN-5804H UV printer?
A: The model number of the HOLDWIN-5804H UV printer is HOLDWIN-5804H UV.

Q: How many print heads does the HOLDWIN-5804H UV printer have?
A: The HOLDWIN-5804H UV printer has four Epsoni3200-U1 print heads.

Q: What type of printing technology does the HOLDWIN-5804H UV printer use?
A: The HOLDWIN-5804H UV printer uses grayscale piezoelectric inkjet printing technology.

Q: What is the ink drop size for the HOLDWIN-5804H UV printer?
A: The ink drop size for the HOLDWIN-5804H UV printer is 3.5 pl.

Q: What is the maximum width that can be printed by the HOLDWIN-5804H UV printer?
A: The maximum width that can be printed by the HOLDWIN-5804H UV printer is 1800 mm.

Q: What is the acceptable media thickness for the HOLDWIN-5804H UV printer?
A: The acceptable media thickness for the HOLDWIN-5804H UV printer is 1 mm.

Q: What is the weight capacity for the acceptable media for the HOLDWIN-5804H UV printer?
A: The weight capacity for the acceptable media for the HOLDWIN-5804H UV printer is 60 kg.

Q: What type of ink curing unit does the HOLDWIN-5804H UV printer have?
A: The HOLDWIN-5804H UV printer has dual UV LED lamps (water-cooling UV lamp) as its ink curing unit.

Q: What is the capacity of the continual ink supply system for the HOLDWIN-5804H UV printer?
A: The capacity of the continual ink supply system for the HOLDWIN-5804H UV printer is 1.5L ink tank.

Q: What colors are available for the ink used in the HOLDWIN-5804H UV printer?
A: The colors available for the ink used in the HOLDWIN-5804H UV printer include CMYK, CMYK+W, CMYK+W+CMYK, Scrub, and Gild.

Q: What is the printing resolution range for the HOLDWIN-5804H UV printer?
A: The printing resolution range for the HOLDWIN-5804H UV printer is 300 / 600 / 900 / 1200 dpi.

Q: What interface does the HOLDWIN-5804H UV printer use to connect to a computer?
A: The HOLDWIN-5804H UV printer uses LAN as its interface to connect to a computer.

Q: What is the power supply voltage for the HOLDWIN-5804H UV printer?
A: The power supply voltage for the HOLDWIN-5804H UV printer is AC 220V ±10%, 16A, 50 HZ ± 1, 5000W.

Q: What RIP software comes with the HOLDWIN-5804H UV printer?
A: The RIP software that comes with the HOLDWIN-5804H UV printer is Riprint UV.

Q: What is the size and weight of the HOLDWIN-5804H UV printer when it is packaged?
A: The package size and weight of the HOLDWIN-5804H UV printer are 3350 * 1130 * 1740 mm and 520 kg respectively.

Q: What is the recommended temperature and humidity range for operating the HOLDWIN-5804H UV printer when it is turned on?
A: The recommended temperature and humidity range for operating the HOLDWIN-5804H UV printer when it is turned on are 15°C to 32°C and 35% to 80% (no condensation) respectively.

Q: What is the recommended temperature and humidity range for storing the HOLDWIN-5804H UV printer when it is turned off?
A: The recommended temperature and humidity range for storing the HOLDWIN-5804H UV printer when it is turned off are 5°C to 40°C and 20% to 80% (no condensation) respectively.

Q: What accessories come with the HOLDWIN-5804H UV printer?
A: The accessories that come with the HOLDWIN-5804H UV printer include USB cable, media clamp, manual, drain bottle, ink cartridges, and Riprint UV software.
